X-ray diffraction
2.1Å resolution

Crystal structure of Mus musculus (Mm) Endonuclease V in complex with a 23mer RNA oligo containing an inosine after a 2 min soak in Mn2+


Function and Biology Details

Biochemical function:
  • not assigned
Biological process:
  • not assigned
Cellular component:
  • not assigned
Sequence domain:

Structure analysis Details

Assembly composition:
hetero tetramer (preferred)
Entry contents:
1 distinct polypeptide molecule
1 distinct DNA/RNA hybrid molecule
Macromolecules (2 distinct):
Endonuclease V Chains: A, B
Molecule details ›
Chains: A, B
Length: 253 amino acids
Theoretical weight: 28.05 KDa
Source organism: Mus musculus
Expression system: Escherichia coli
  • Canonical: Q8C9A2 (Residues: 1-253; Coverage: 75%)
Gene name: Endov
Sequence domains: Endonuclease V
Molecule details ›
Chains: C, D
Length: 23 nucleotides
Theoretical weight: 7.29 KDa
Source organism: synthetic construct
Expression system: Not provided

Ligands and Environments

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: APS BEAMLINE 22-BM
Spacegroup: P212121
Unit cell:
a: 73.621Å b: 72.519Å c: 155.764Å
α: 90° β: 90° γ: 90°
R R work R free
0.178 0.176 0.217
Expression systems:
  • Escherichia coli
  • Not provided
