X-ray diffraction
2.4Å resolution

Crystal structure of AKT1 (aa 144-480) with a bisubstrate


Function and Biology Details

Reactions catalysed:
ATP + a protein = ADP + a phosphoprotein
ATP + [tau protein] = ADP + [tau protein] phosphate
Biochemical function:
  • not assigned
Biological process:
  • not assigned
Cellular component:
  • not assigned

Structure analysis Details

Assembly composition:
hetero dimer (preferred)
Entry contents:
2 distinct polypeptide molecules
Macromolecules (2 distinct):
RAC-alpha serine/threonine-protein kinase Chains: A, B
Molecule details ›
Chains: A, B
Length: 337 amino acids
Theoretical weight: 39.24 KDa
Source organism: Homo sapiens
Expression system: Spodoptera aff. frugiperda 2 RZ-2014
  • Canonical: P31749 (Residues: 144-480; Coverage: 70%)
Gene names: AKT1, PKB, RAC
Sequence domains:
Structure domains:
Glycogen synthase kinase-3 beta Chains: F, G
Molecule details ›
Chains: F, G
Length: 10 amino acids
Theoretical weight: 1.67 KDa
Source organism: Homo sapiens
Expression system: Not provided
  • Canonical: P49841 (Residues: 3-12; Coverage: 2%)
Gene name: GSK3B

Ligands and Environments

2 bound ligands:
2 modified residues:

Experiments and Validation Details

Entry percentile scores
X-ray source: RIGAKU FR-E+ DW
Spacegroup: P21
Unit cell:
a: 86.628Å b: 56.267Å c: 91.837Å
α: 90° β: 105.1° γ: 90°
R R work R free
0.185 0.183 0.23
Expression systems:
  • Spodoptera aff. frugiperda 2 RZ-2014
  • Not provided
