6ml4

X-ray diffraction
1.48Å resolution

BTB24 Zinc Fingers 4-8 with 19+1mer DNA Oligonucleotide (Sequence 3)

Released:

Function and Biology Details

Biochemical function:
  • not assigned
Biological process:
  • not assigned
Cellular component:
  • not assigned

Structure analysis Details

Assembly composition:
hetero trimer (preferred)
Entry contents:
1 distinct polypeptide molecule
2 distinct DNA molecules
Macromolecules (3 distinct):
Zinc finger and BTB domain-containing protein 24 Chain: A
Molecule details ›
Chain: A
Length: 151 amino acids
Theoretical weight: 17.27 KDa
Source organism: Mus musculus
Expression system: Escherichia coli BL21(DE3)
UniProt:
  • Canonical: Q80X44 (Residues: 375-519; Coverage: 20%)
Gene names: Bif1, Bsg1, Zbtb24, Znf450
Sequence domains: Zinc finger, C2H2 type
DNA (5'-D(*AP*CP*GP*CP*AP*GP*GP*TP*CP*CP*TP*GP*GP*AP*CP*GP*AP*AP*GP*C)-3') Chain: E
Molecule details ›
Chain: E
Length: 20 nucleotides
Theoretical weight: 6.17 KDa
Source organism: Mus musculus
Expression system: Not provided
DNA (5'-D(*TP*GP*CP*TP*TP*CP*GP*TP*CP*CP*AP*GP*GP*AP*CP*CP*TP*GP*CP*G)-3') Chain: F
Molecule details ›
Chain: F
Length: 20 nucleotides
Theoretical weight: 6.1 KDa
Source organism: Mus musculus
Expression system: Not provided

Ligands and Environments

2 bound ligands:
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: RIGAKU MICROMAX-003
Spacegroup: P21
Unit cell:
a: 46.277Å b: 68.807Å c: 48.434Å
α: 90° β: 92.4° γ: 90°
R-values:
R R work R free
0.192 0.191 0.211
Expression systems:
  • Escherichia coli BL21(DE3)
  • Not provided
