PDBe 5zxh

X-ray diffraction
2.8Å resolution

The structure of MT189-tubulin complex

Released:

Function and Biology Details

Structure analysis Details

Assembly composition:
hetero hexamer (preferred)
Entry contents:
4 distinct polypeptide molecules
Macromolecules (4 distinct):
Tubulin alpha-1B chain Chains: A, C
Molecule details ›
Chains: A, C
Length: 450 amino acids
Theoretical weight: 50.04 KDa
Source organism: Sus scrofa
Expression system: Escherichia coli
UniProt:
  • Canonical: Q2XVP4 (Residues: 1-450; Coverage: 100%)
Gene name: TUBA1B
Sequence domains:
Tubulin beta-2B chain Chains: B, D
Molecule details ›
Chains: B, D
Length: 445 amino acids
Theoretical weight: 49.95 KDa
Source organism: Bos taurus
Expression system: Escherichia coli
UniProt:
  • Canonical: Q6B856 (Residues: 1-445; Coverage: 100%)
Gene name: TUBB2B
Sequence domains:
Stathmin-4 Chain: E
Molecule details ›
Chain: E
Length: 143 amino acids
Theoretical weight: 16.84 KDa
Source organism: Rattus norvegicus
Expression system: Escherichia coli
UniProt:
  • Canonical: P63043 (Residues: 49-189; Coverage: 75%)
Gene name: Stmn4
Sequence domains: Stathmin family
Tubulin tyrosine ligase Chain: F
Molecule details ›
Chain: F
Length: 384 amino acids
Theoretical weight: 44.38 KDa
Source organism: Gallus gallus
Expression system: Escherichia coli
UniProt:
  • Canonical: E1BQ43 (Residues: 1-378; Coverage: 100%)
Gene name: TTL
Sequence domains: Tubulin-tyrosine ligase family

Ligands and Environments


No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: SSRF BEAMLINE BL17U1
Spacegroup: P212121
Unit cell:
a: 104.91Å b: 157.06Å c: 182.838Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.211 0.208 0.259
Expression system: Escherichia coli
