› 5xf4

X-ray diffraction
2.87Å resolution

Nucleosome core particle with an adduct of a binuclear RAPTA (Ru-arene-phosphaadamantane) compound having a 1,2-diphenylethylenediamine linker (S,S-configuration)

Released:
DOI: 10.2210/pdb5xf4/pdb
PDB 5xf4 coloured by chain and viewed from the front.
PDB 5xf4 coloured by chain and viewed from the side.
PDB 5xf4 coloured by chain and viewed from the top.
Source organism: Homo sapiens
Primary publication:
Nucleosome acidic patch-targeting binuclear ruthenium compounds induce aberrant chromatin condensation.
Davey GE, Adhireksan Z, Ma Z, Riedel T, Sharma D, Padavattan S, Rhodes D, Ludwig A, Sandin S, Murray BS, Dyson PJ, Davey CA
Nat Commun 8 1575 (2017)
PMID: 29146919

Function and Biology Details

Biochemical function:
Biological process:
Cellular component:
Sequence domains:

Structure analysis Details

Assembly composition:
hetero decamer (preferred)
Entry contents:
4 distinct polypeptide molecules
2 distinct DNA molecules
Macromolecules (6 distinct):
Histone H3.1 Chains: A, E
Molecule details ›
Chains: A, E
Length: 136 amino acids
Theoretical weight: 15.44 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P68431 (Residues: 1-136; Coverage: 100%)
Gene names: H3C1, H3C10, H3C11, H3C12, H3C2, H3C3, H3C4, H3C6, H3C7, H3C8, H3FA, H3FB, H3FC HIST1H3C, H3FD, H3FF, H3FH, H3FI, H3FJ, H3FK, H3FL, HIST1H3A, HIST1H3B, HIST1H3D, HIST1H3E, HIST1H3F, HIST1H3G, HIST1H3H, HIST1H3I, HIST1H3J
Sequence domains: Core histone H2A/H2B/H3/H4
Structure domains: Histone, subunit A
Histone H4 Chains: B, F
Molecule details ›
Chains: B, F
Length: 103 amino acids
Theoretical weight: 11.39 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P62805 (Residues: 1-103; Coverage: 100%)
Gene names: H4-16, H4/A, H4/B, H4/C, H4/D, H4/E, H4/G, H4/H, H4/I, H4/J, H4/K, H4/M, H4/N, H4/O, H4C1, H4C11, H4C12, H4C13, H4C14, H4C15, H4C16, H4C2, H4C3, H4C4, H4C5, H4C6, H4C8, H4C9, H4F2, H4FA, H4FB, H4FC, H4FD, H4FE, H4FG, H4FH, H4FI, H4FJ, H4FK, H4FM, H4FN, H4FO, HIST1H4A, HIST1H4B, HIST1H4C, HIST1H4D, HIST1H4E, HIST1H4F, HIST1H4H, HIST1H4I, HIST1H4J, HIST1H4K, HIST1H4L, HIST2H4, HIST2H4A, HIST2H4B, HIST4H4
Sequence domains: Centromere kinetochore component CENP-T histone fold
Structure domains: Histone, subunit A
Histone H2A type 1-B/E Chains: C, G
Molecule details ›
Chains: C, G
Length: 130 amino acids
Theoretical weight: 14.17 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P04908 (Residues: 1-130; Coverage: 100%)
Gene names: H2AC4, H2AC8, H2AFA, H2AFM, HIST1H2AB, HIST1H2AE
Sequence domains:
Structure domains: Histone, subunit A
Histone H2B type 1-J Chains: D, H
Molecule details ›
Chains: D, H
Length: 126 amino acids
Theoretical weight: 13.94 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P06899 (Residues: 1-126; Coverage: 100%)
Gene names: H2BC11, H2BFR, HIST1H2BJ
Sequence domains: Core histone H2A/H2B/H3/H4
Structure domains: Histone, subunit A
DNA (145-MER) Chain: I
Molecule details ›
Chain: I
Length: 145 nucleotides
Theoretical weight: 44.75 KDa
DNA (145-MER) Chain: J
Molecule details ›
Chain: J
Length: 145 nucleotides
Theoretical weight: 44.74 KDa

Ligands and Environments

4 bound ligands:
Ligand MG 1 x MG
Ligand RUD 2 x RUD
Ligand SSK 1 x SSK
Ligand SO4 1 x SO4
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: SLS BEAMLINE X06DA
Spacegroup: P212121
Unit cell:
a: 107.76Å b: 109.56Å c: 175.22Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.228 0.227 0.266
Expression system: Escherichia coli
