X-ray diffraction
1.84Å resolution

Crystal structure of human Protein kinase CK2 catalytic subunit in complex with the ATP-competitive, tight-binding dibenzofuran inhibitor TF85 (4a)


Function and Biology Details

Reaction catalysed:
ATP + a protein = ADP + a phosphoprotein
Biochemical function:
  • not assigned
Biological process:
  • not assigned
Cellular component:
  • not assigned

Structure analysis Details

Assembly composition:
monomeric (preferred)
Entry contents:
1 distinct polypeptide molecule
Casein kinase II subunit alpha Chain: A
Molecule details ›
Chain: A
Length: 335 amino acids
Theoretical weight: 40.07 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
  • Canonical: P68400 (Residues: 1-335; Coverage: 86%)
Gene names: CK2A1, CSNK2A1
Sequence domains: Protein kinase domain
Structure domains:

Ligands and Environments

3 bound ligands:
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: SLS BEAMLINE X06DA
Spacegroup: P21
Unit cell:
a: 57.477Å b: 45.505Å c: 63.489Å
α: 90° β: 110.97° γ: 90°
R R work R free
0.169 0.167 0.201
Expression system: Escherichia coli
