5lhd

X-ray diffraction
2.6Å resolution

Structure of glycosylated human aminopeptidase N

Released:

Function and Biology Details

Reaction catalysed:
Release of an N-terminal amino acid, Xaa-|-Yaa- from a peptide, amide or arylamide. Xaa is preferably Ala, but may be most amino acids including Pro (slow action). When a terminal hydrophobic residue is followed by a prolyl residue, the two may be released as an intact Xaa-Pro dipeptide.
Biochemical function:
Biological process:
Cellular component:

Structure analysis Details

Assembly composition:
monomeric (preferred)
Assembly name:
PDBe Complex ID:
PDB-CPX-147231 (preferred)
Entry contents:
1 distinct polypeptide molecule
Macromolecules (8 distinct):
Aminopeptidase N Chains: A, B, C, D
Molecule details ›
Chains: A, B, C, D
Length: 950 amino acids
Theoretical weight: 107.96 KDa
Source organism: Homo sapiens
Expression system: Cricetulus griseus
UniProt:
  • Canonical: P15144 (Residues: 36-967; Coverage: 96%)
Gene names: ANPEP, APN, CD13, PEPN
Sequence domains:
Structure domains:

Ligands and Environments

Carbohydrate polymer : NEW Components: NAG, BMA
Carbohydrate polymer : NEW Components: NAG, BMA
Carbohydrate polymer : NEW Components: NAG
Carbohydrate polymer : NEW Components: NAG, BMA
Carbohydrate polymer : NEW Components: NAG, BMA
Carbohydrate polymer : NEW Components: NAG, BMA
Carbohydrate polymer : NEW Components: NAG, BMA
3 bound ligands:
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: SLS BEAMLINE X10SA
Spacegroup: P212121
Unit cell:
a: 127.093Å b: 168.856Å c: 244.249Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.183 0.182 0.214
Expression system: Cricetulus griseus
