PDBe 5he0

X-ray diffraction
2.56Å resolution

Function and Biology Details

Reaction catalysed:
ATP + [beta-adrenergic receptor] = ADP + [beta-adrenergic receptor] phosphate.
Biochemical function:
Biological process:
Cellular component:

Structure analysis Details

Assembly composition:
hetero trimer (preferred)
Entry contents:
3 distinct polypeptide molecules
Macromolecules (3 distinct):
Beta-adrenergic receptor kinase 1 Chain: A
Molecule details ›
Chain: A
Length: 641 amino acids
Theoretical weight: 74.76 KDa
Source organism: Bos taurus
Expression system: Trichoplusia ni
UniProt:
  • Canonical: P21146 (Residues: 30-669; Coverage: 93%)
Gene names: ADRBK1, GRK2
Sequence domains:
Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1 Chain: B
Molecule details ›
Chain: B
Length: 339 amino acids
Theoretical weight: 37.29 KDa
Source organism: Homo sapiens
Expression system: Trichoplusia ni
UniProt:
  • Canonical: P62873 (Residues: 2-340; Coverage: 100%)
Gene name: GNB1
Sequence domains: WD domain, G-beta repeat
Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2 Chain: G
Molecule details ›
Chain: G
Length: 71 amino acids
Theoretical weight: 7.86 KDa
Source organism: Homo sapiens
Expression system: Trichoplusia ni
UniProt:
  • Canonical: P59768 (Residues: 1-71; Coverage: 100%)
Gene name: GNG2
Sequence domains: GGL domain

Ligands and Environments

1 bound ligand:

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: APS BEAMLINE 21-ID-G
Spacegroup: C2221
Unit cell:
a: 60.554Å b: 239.927Å c: 208.872Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.205 0.202 0.264
Expression system: Trichoplusia ni
