X-ray diffraction
2.3Å resolution

Crystal structure of AF9 YEATS bound to H3K9ac peptide


Function and Biology Details

Biochemical function:
  • not assigned
Biological process:
  • not assigned
Cellular component:
  • not assigned
Sequence domains:

Structure analysis Details

Assembly composition:
hetero dimer (preferred)
Entry contents:
2 distinct polypeptide molecules
Macromolecules (2 distinct):
Protein AF-9 Chains: A, C
Molecule details ›
Chains: A, C
Length: 141 amino acids
Theoretical weight: 16.61 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli BL21(DE3)
  • Canonical: P42568 (Residues: 1-138; Coverage: 24%)
Gene names: AF9, MLLT3, YEATS3
Sequence domains: YEATS family
Structure domains: YEATS domain
Histone H3.3 Chains: B, D
Molecule details ›
Chains: B, D
Length: 11 amino acids
Theoretical weight: 1.29 KDa
Source organism: Homo sapiens
Expression system: Not provided
  • Canonical: P84243 (Residues: 2-12; Coverage: 8%)
Gene names: H3-3A, H3-3B, H3.3A, H3.3B, H3F3, H3F3A, H3F3B, PP781

Ligands and Environments

1 bound ligand:
1 modified residue:

Experiments and Validation Details

Entry percentile scores
X-ray source: SSRF BEAMLINE BL17U
Spacegroup: C2221
Unit cell:
a: 42.537Å b: 195.704Å c: 106.675Å
α: 90° β: 90° γ: 90°
R R work R free
0.166 0.162 0.229
Expression systems:
  • Escherichia coli BL21(DE3)
  • Not provided
