X-ray diffraction
3.2Å resolution

Crystal Structure of Human Nucleosome Core Particle lacking H2B N-terminal region

Released:
DOI: 10.2210/pdb3w97/pdb
PDB entry 3w97 coloured by chain, front view.
PDB entry 3w97 coloured by chain, side view.
PDB entry 3w97 coloured by chain, top view.
Source organism: Homo sapiens
Primary publication:
Contribution of histone N-terminal tails to the structure and stability of nucleosomes.
Iwasaki W, Miya Y, Horikoshi N, Osakabe A, Taguchi H, Tachiwana H, Shibata T, Kagawa W, Kurumizaka H
OpenAccess logo FEBS Open Bio 3 363-9 (2013)
PMID: 24251097

Function and Biology Details

Biochemical function:
Biological process:
Cellular component:
Sequence domains:

Structure analysis Details

Assembly composition:
hetero decamer (preferred)
Assembly name:
PDBe Complex ID:
PDB-CPX-117072 (preferred)
Entry contents:
4 distinct polypeptide molecules
1 distinct DNA molecule
Macromolecules (5 distinct):
Histone H3.1 Chains: A, E
Molecule details ›
Chains: A, E
Length: 139 amino acids
Theoretical weight: 15.72 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P68431 (Residues: 1-136; Coverage: 100%)
Gene names: H3C1, H3C10, H3C11, H3C12, H3C2, H3C3, H3C4, H3C6, H3C7, H3C8, H3FA, H3FB, H3FC HIST1H3C, H3FD, H3FF, H3FH, H3FI, H3FJ, H3FK, H3FL, HIST1H3A, HIST1H3B, HIST1H3D, HIST1H3E, HIST1H3F, HIST1H3G, HIST1H3H, HIST1H3I, HIST1H3J
Sequence domains: Core histone H2A/H2B/H3/H4
Structure domains: Histone, subunit A
Histone H4 Chains: B, F
Molecule details ›
Chains: B, F
Length: 106 amino acids
Theoretical weight: 11.68 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P62805 (Residues: 1-103; Coverage: 100%)
Gene names: H4-16, H4/A, H4/B, H4/C, H4/D, H4/E, H4/G, H4/H, H4/I, H4/J, H4/K, H4/M, H4/N, H4/O, H4C1, H4C11, H4C12, H4C13, H4C14, H4C15, H4C16, H4C2, H4C3, H4C4, H4C5, H4C6, H4C8, H4C9, H4F2, H4FA, H4FB, H4FC, H4FD, H4FE, H4FG, H4FH, H4FI, H4FJ, H4FK, H4FM, H4FN, H4FO, HIST1H4A, HIST1H4B, HIST1H4C, HIST1H4D, HIST1H4E, HIST1H4F, HIST1H4H, HIST1H4I, HIST1H4J, HIST1H4K, HIST1H4L, HIST2H4, HIST2H4A, HIST2H4B, HIST4H4
Sequence domains: Centromere kinetochore component CENP-T histone fold
Structure domains: Histone, subunit A
Histone H2A type 1-B/E Chains: C, G
Molecule details ›
Chains: C, G
Length: 133 amino acids
Theoretical weight: 14.45 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P04908 (Residues: 1-130; Coverage: 100%)
Gene names: H2AC4, H2AC8, H2AFA, H2AFM, HIST1H2AB, HIST1H2AE
Sequence domains:
Structure domains: Histone, subunit A
Histone H2B type 1-J Chains: D, H
Molecule details ›
Chains: D, H
Length: 105 amino acids
Theoretical weight: 11.75 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P06899 (Residues: 26-126; Coverage: 80%)
Gene names: H2BC11, H2BFR, HIST1H2BJ
Sequence domains: Core histone H2A/H2B/H3/H4
Structure domains: Histone, subunit A
146-mer DNA Chains: I, J
Molecule details ›
Chains: I, J
Length: 146 nucleotides
Theoretical weight: 45.05 KDa

Ligands and Environments

1 bound ligand:
Ligand MN 1 x MN
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: PHOTON FACTORY BEAMLINE AR-NW12A
Spacegroup: P212121
Unit cell:
a: 105.839Å b: 109.728Å c: 175.41Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.269 0.269 0.321
Expression system: Escherichia coli
