X-ray diffraction
4.5Å resolution

Crystal structure of respiratory complex I from Thermus thermophilus

Released:
DOI: 10.2210/pdb3m9s/pdb
PDB entry 3m9s coloured by chain, front view.
PDB entry 3m9s coloured by chain, side view.
PDB entry 3m9s coloured by chain, top view.
Source organism: Thermus thermophilus HB8
Primary publication:
The architecture of respiratory complex I.
Efremov RG, Baradaran R, Sazanov LA
Nature 465 441-5 (2010)
PMID: 20505720

Function and Biology Details

Biochemical function:
Biological process:
Cellular component:
Sequence domains:

Structure analysis Details

Assembly composition:
hetero tridecamer (preferred)
PDBe Complex ID:
PDB-CPX-163776 (preferred)
Entry contents:
13 distinct polypeptide molecules
Macromolecules (13 distinct):
NADH-quinone oxidoreductase subunit 1 Chains: 1, A
Molecule details ›
Chains: 1, A
Length: 438 amino acids
Theoretical weight: 48.69 KDa
Source organism: Thermus thermophilus HB8
UniProt:
  • Canonical: Q56222 (Residues: 1-438; Coverage: 100%)
Gene names: TTHA0089, nqo1
Sequence domains:
NADH-quinone oxidoreductase subunit 2 Chains: 2, B
Molecule details ›
Chains: 2, B
Length: 181 amino acids
Theoretical weight: 20.31 KDa
Source organism: Thermus thermophilus HB8
UniProt:
  • Canonical: Q56221 (Residues: 1-181; Coverage: 100%)
Gene names: TTHA0088, nqo2
Sequence domains: Thioredoxin-like [2Fe-2S] ferredoxin
NADH-quinone oxidoreductase subunit 3 Chains: 3, C
Molecule details ›
Chains: 3, C
Length: 783 amino acids
Theoretical weight: 86.66 KDa
Source organism: Thermus thermophilus HB8
UniProt:
  • Canonical: Q56223 (Residues: 1-783; Coverage: 100%)
Gene names: TTHA0090, nqo3
Sequence domains:
NADH-quinone oxidoreductase subunit 4 Chains: 4, D
Molecule details ›
Chains: 4, D
Length: 409 amino acids
Theoretical weight: 46.43 KDa
Source organism: Thermus thermophilus HB8
UniProt:
  • Canonical: Q56220 (Residues: 1-409; Coverage: 100%)
Gene names: TTHA0087, nqo4
Sequence domains: Respiratory-chain NADH dehydrogenase, 49 Kd subunit
NADH-quinone oxidoreductase subunit 5 Chains: 5, E
Molecule details ›
Chains: 5, E
Length: 207 amino acids
Theoretical weight: 23.89 KDa
Source organism: Thermus thermophilus HB8
UniProt:
  • Canonical: Q56219 (Residues: 1-207; Coverage: 100%)
Gene names: TTHA0086, nqo5
Sequence domains: Respiratory-chain NADH dehydrogenase, 30 Kd subunit
NADH-quinone oxidoreductase subunit 6 Chains: 6, F
Molecule details ›
Chains: 6, F
Length: 181 amino acids
Theoretical weight: 20.26 KDa
Source organism: Thermus thermophilus HB8
UniProt:
  • Canonical: Q56218 (Residues: 1-181; Coverage: 100%)
Gene names: TTHA0085, nqo6
Sequence domains: NADH ubiquinone oxidoreductase, 20 Kd subunit
NADH-quinone oxidoreductase subunit 9 Chains: 9, G
Molecule details ›
Chains: 9, G
Length: 182 amino acids
Theoretical weight: 20.11 KDa
Source organism: Thermus thermophilus HB8
UniProt:
  • Canonical: Q56224 (Residues: 1-182; Coverage: 100%)
Gene names: TTHA0092, nqo9
Sequence domains: 4Fe-4S binding domain
NADH-quinone oxidoreductase subunit 15 Chains: 7, J
Molecule details ›
Chains: 7, J
Length: 129 amino acids
Theoretical weight: 14.81 KDa
Source organism: Thermus thermophilus HB8
UniProt:
  • Canonical: Q5SKZ7 (Residues: 1-129; Coverage: 100%)
Gene names: TTHA0496, nqo15
Sequence domains: NADH-quinone oxidoreductase chain 15
NADH-quinone oxidoreductase subunit 12 Chains: L, O
Molecule details ›
Chains: L, O
Length: 469 amino acids
Theoretical weight: 39.93 KDa
Source organism: Thermus thermophilus HB8
NADH-quinone oxidoreductase subunit 13 Chains: M, P
Molecule details ›
Chains: M, P
Length: 392 amino acids
Theoretical weight: 33.38 KDa
Source organism: Thermus thermophilus HB8
NADH-quinone oxidoreductase subunit 14 Chains: N, Q
Molecule details ›
Chains: N, Q
Length: 379 amino acids
Theoretical weight: 32.27 KDa
Source organism: Thermus thermophilus HB8
NADH-quinone oxidoreductase subunits 7, 10 and 11 Chains: R, S
Molecule details ›
Chains: R, S
Length: 274 amino acids
Theoretical weight: 23.34 KDa
Source organism: Thermus thermophilus HB8
NADH-quinone oxidoreductase subunit 8 Chains: H, T
Molecule details ›
Chains: H, T
Length: 181 amino acids
Theoretical weight: 15.42 KDa
Source organism: Thermus thermophilus HB8

Ligands and Environments

3 bound ligands:
Ligand SF4 14 x SF4
Ligand FMN 2 x FMN
Ligand FES 4 x FES
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: SLS BEAMLINE X06SA
Spacegroup: P21
Unit cell:
a: 96.39Å b: 336.09Å c: 262.24Å
α: 90° β: 100.59° γ: 90°
