› 3klg

X-ray diffraction
3.65Å resolution

Crystal structure of AZT-resistant HIV-1 Reverse Transcriptase crosslinked to pre-translocation AZTMP-Terminated DNA (COMPLEX N)

Released:
DOI: 10.2210/pdb3klg/pdb
PDB entry 3klg coloured by chain, front view.
PDB entry 3klg coloured by chain, side view.
PDB entry 3klg coloured by chain, top view.
Source organism: Human immunodeficiency virus type 1 BH10
Primary publication:
Structural basis of HIV-1 resistance to AZT by excision.
Tu X, Das K, Han Q, Bauman JD, Clark AD, Hou X, Frenkel YV, Gaffney BL, Jones RA, Boyer PL, Hughes SH, Sarafianos SG, Arnold E
Nat Struct Mol Biol 17 1202-9 (2010)
PMID: 20852643

Function and Biology Details

Reactions catalysed:
Deoxynucleoside triphosphate + DNA(n) = diphosphate + DNA(n+1)
3'-end directed exonucleolytic cleavage of viral RNA-DNA hybrid
Endohydrolysis of RNA in RNA/DNA hybrids. Three different cleavage modes: 1. sequence-specific internal cleavage of RNA. Human immunodeficiency virus type 1 and Moloney murine leukemia virus enzymes prefer to cleave the RNA strand one nucleotide away from the RNA-DNA junction. 2. RNA 5'-end directed cleavage 13-19 nucleotides from the RNA end. 3. DNA 3'-end directed cleavage 15-20 nucleotides away from the primer terminus.
Specific for a P1 residue that is hydrophobic, and P1' variable, but often Pro.
Biochemical function:
Biological process:
Cellular component:
  • not assigned
Sequence domains:

Structure analysis Details

Assembly composition:
hetero tetramer (preferred)
Assembly name:
PDBe Complex ID:
PDB-CPX-116489 (preferred)
Entry contents:
2 distinct polypeptide molecules
2 distinct DNA molecules
Macromolecules (4 distinct):
Reverse transcriptase/ribonuclease H Chains: A, E
Molecule details ›
Chains: A, E
Length: 562 amino acids
Theoretical weight: 64.76 KDa
Source organism: Human immunodeficiency virus type 1 BH10
Expression system: Escherichia coli
UniProt:
  • Canonical: P03366 (Residues: 600-1159; Coverage: 39%)
Gene name: gag-pol
Sequence domains:
Structure domains:
p51 RT Chains: B, F
Molecule details ›
Chains: B, F
Length: 437 amino acids
Theoretical weight: 51.12 KDa
Source organism: Human immunodeficiency virus type 1 BH10
Expression system: Escherichia coli
UniProt:
  • Canonical: P03366 (Residues: 600-1027; Coverage: 30%)
Gene name: gag-pol
Sequence domains:
Structure domains:
DNA (5'-D(*AP*T*GP*CP*AP*TP*GP*GP*CP*GP*CP*CP*CP*GP*AP*AP*CP*AP*GP*GP*GP*AP*CP*TP*GP*TP*G)-3') Chains: C, G
Molecule details ›
Chains: C, G
Length: 27 nucleotides
Theoretical weight: 8.37 KDa
DNA (5'-D(*A*CP*AP*GP*TP*CP*CP*CP*TP*GP*TP*TP*CP*GP*GP*(MRG)P*CP*GP*CP*CP*AP*(ATM))-3') Chains: D, H
Molecule details ›
Chains: D, H
Length: 22 nucleotides
Theoretical weight: 6.8 KDa

Ligands and Environments

No bound ligands
2 modified residues:
Ligand MRG 2 x MRG
Ligand ATM 2 x ATM

Experiments and Validation Details

Entry percentile scores
X-ray source: CHESS BEAMLINE F1
Spacegroup: P212121
Unit cell:
a: 79.12Å b: 154.4Å c: 277.92Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.312 0.312 0.35
Expression system: Escherichia coli
