› 2pyi

X-ray diffraction
1.88Å resolution

Function and Biology Details

Reaction catalysed:
((1->4)-alpha-D-glucosyl)(n) + phosphate = ((1->4)-alpha-D-glucosyl)(n-1) + alpha-D-glucose 1-phosphate
Biochemical function:
Biological process:
Cellular component:
Sequence domains:
Structure domain:

Structure analysis Details

Assemblies composition:
homo dimer
monomeric (preferred)
Assembly name:
PDBe Complex ID:
PDB-CPX-132555 (preferred)
Entry contents:
1 distinct polypeptide molecule
Macromolecule:
Glycogen phosphorylase, muscle form Chain: A
Molecule details ›
Chain: A
Length: 843 amino acids
Theoretical weight: 97.65 KDa
Source organism: Oryctolagus cuniculus
UniProt:
  • Canonical: P00489 (Residues: 1-843; Coverage: 100%)
Gene name: PYGM
Sequence domains: Carbohydrate phosphorylase
Structure domains: Glycogen Phosphorylase B;

Ligands and Environments

2 bound ligands:
Ligand DL8 1 x DL8
Ligand DMS 10 x DMS
1 modified residue:
Ligand LLP 1 x LLP

Experiments and Validation Details

Entry percentile scores
X-ray source: EMBL/DESY, HAMBURG BEAMLINE X13
Spacegroup: P43212
Unit cell:
a: 125.934Å b: 125.934Å c: 115.287Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.202 0.2 0.238

Quick links

Citations

7 citation in other articles

Kinetics, in silico docking, molecular dynamics, and MM-GBSA binding studies on prototype indirubins, KT5720, and staurosporine as phosphorylase kinase ATP-binding site inhibitors: the role of water molecules examined.
Hayes et al. (2011)
6 more
