2f15

X-ray diffraction
2Å resolution

Glycogen-Binding Domain Of The Amp-Activated Protein Kinase beta2 Subunit

Released:
Source organism: Homo sapiens
Entry authors: Walker JR, Wybenga-Groot L, Finerty Jr PJ, Newman E, MacKenzie FM, Weigelt J, Sundstrom M, Arrowsmith C, Edwards A, Bochkarev A, Dhe-Paganon S, Structural Genomics Consortium (SGC)

Function and Biology Details

Structure analysis Details

Assembly composition:
monomeric (preferred)
Entry contents:
1 distinct polypeptide molecule
Macromolecule:
5'-AMP-activated protein kinase subunit beta-2 Chain: A
Molecule details ›
Chain: A
Length: 96 amino acids
Theoretical weight: 10.87 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli BL21
UniProt:
  • Canonical: O43741 (Residues: 69-163; Coverage: 35%)
Gene name: PRKAB2
Sequence domains: Glycogen recognition site of AMP-activated protein kinase
Structure domains: Immunoglobulins

Ligands and Environments

No bound ligands

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: RIGAKU FR-E
Spacegroup: R32
Unit cell:
a: 69.723Å b: 69.723Å c: 118.491Å
α: 90° β: 90° γ: 120°
R-values:
R R work R free
0.239 0.237 0.296
Expression system: Escherichia coli BL21
