X-ray diffraction
1.6Å resolution

Crystal structure of the alpha-adaptin appendage domain, from the AP2 adaptor complex, in complex with an FXDNF peptide from amphiphysin1 and a WVXF peptide from synaptojanin P170


Function and Biology Details

Structure analysis Details

Assembly composition:
Non-polymer only trimer (preferred)
Entry contents:
3 distinct polypeptide molecules
Macromolecules (3 distinct):
AP-2 complex subunit alpha-2 Chain: A
Molecule details ›
Chain: A
Length: 250 amino acids
Theoretical weight: 28.05 KDa
Source organism: Mus musculus
Expression system: Escherichia coli BL21
  • Canonical: P17427 (Residues: 690-938; Coverage: 27%)
Gene names: Adtab, Ap2a2
Sequence domains:
Structure domains:
Synaptojanin-1 Chain: P
Molecule details ›
Chain: P
Length: 12 amino acids
Theoretical weight: 1.47 KDa
Source organism: Homo sapiens
Expression system: Not provided
  • Canonical: O43426 (Residues: 1477-1488; Coverage: 1%)
Gene names: KIAA0910, SYNJ1
Amphiphysin Chain: Q
Molecule details ›
Chain: Q
Length: 7 amino acids
Theoretical weight: 867 Da
Source organism: Rattus norvegicus
Expression system: Not provided
  • Canonical: O08838 (Residues: 324-330; Coverage: 1%)
Gene names: Amph, Amph1

Ligands and Environments

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: SRS BEAMLINE PX9.6
Spacegroup: C2
Unit cell:
a: 144.508Å b: 66.98Å c: 39.73Å
α: 90° β: 94.92° γ: 90°
R R work R free
0.182 0.181 0.208
Expression systems:
  • Escherichia coli BL21
  • Not provided
