X-ray diffraction
1.6Å resolution

beta appendage of AP2 complexed with ARH peptide


Function and Biology Details

Structure analysis Details

Assembly composition:
hetero trimer (preferred)
Entry contents:
3 distinct polypeptide molecules
Macromolecules (3 distinct):
AP-2 complex subunit beta Chain: A
Molecule details ›
Chain: A
Length: 258 amino acids
Theoretical weight: 29.09 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
  • Canonical: P63010 (Residues: 701-937; Coverage: 25%)
Gene names: ADTB2, AP2B1, CLAPB1
Sequence domains:
Structure domains:
Low density lipoprotein receptor adapter protein 1 Chain: P
Molecule details ›
Chain: P
Length: 16 amino acids
Theoretical weight: 1.78 KDa
Source organism: Homo sapiens
Expression system: Not provided
  • Canonical: Q5SW96 (Residues: 252-267; Coverage: 5%)
Gene names: ARH, LDLRAP1
peptide sequence AAF Chain: S
Molecule details ›
Chain: S
Length: 3 amino acids
Theoretical weight: 307 Da

Ligands and Environments

No bound ligands
No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: ESRF BEAMLINE ID23-1
Spacegroup: P21
Unit cell:
a: 37.75Å b: 36.313Å c: 98.982Å
α: 90° β: 92.91° γ: 90°
R R work R free
0.216 0.215 0.243
Expression systems:
  • Escherichia coli
  • Not provided
