1jy2

X-ray diffraction
1.4Å resolution

Crystal Structure of the Central Region of Bovine Fibrinogen (E5 fragment) at 1.4 Angstroms Resolution

Released:
Source organism: Bos taurus

Function and Biology Details

Structure analysis Details

Assembly composition:
Non-polymer only hexamer (preferred)
Entry contents:
3 distinct polypeptide molecules
Macromolecules (3 distinct):
Fibrinogen alpha chain Chains: N, Q
Molecule details ›
Chains: N, Q
Length: 53 amino acids
Theoretical weight: 6.17 KDa
Source organism: Bos taurus
UniProt:
  • Canonical: P02672 (Residues: 48-100; Coverage: 9%)
Gene name: FGA
Structure domains: Single alpha-helices involved in coiled-coils or other helix-helix interfaces
Fibrinogen beta chain Chains: O, R
Molecule details ›
Chains: O, R
Length: 56 amino acids
Theoretical weight: 6.25 KDa
Source organism: Bos taurus
UniProt:
  • Canonical: P02676 (Residues: 61-116; Coverage: 12%)
Gene name: FGB
Structure domains: Single alpha-helices involved in coiled-coils or other helix-helix interfaces
Fibrinogen gamma-B chain Chains: P, S
Molecule details ›
Chains: P, S
Length: 48 amino acids
Theoretical weight: 5.48 KDa
Source organism: Bos taurus
UniProt:
  • Canonical: P12799 (Residues: 25-72; Coverage: 11%)
Gene name: FGG
Structure domains: Single alpha-helices involved in coiled-coils or other helix-helix interfaces

Ligands and Environments

No bound ligands

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: CHESS BEAMLINE A1
Spacegroup: P21
Unit cell:
a: 49.376Å b: 66.222Å c: 50.658Å
α: 90° β: 106.55° γ: 90°
R-values:
R R work R free
0.216 0.216 0.236
