PDBe 1j59

X-ray diffraction
2.5Å resolution

CATABOLITE GENE ACTIVATOR PROTEIN (CAP)/DNA COMPLEX + ADENOSINE-3',5'-CYCLIC-MONOPHOSPHATE

Released:

Function and Biology Details

Structure analysis Details

Assembly composition:
hetero hexamer (preferred)
Entry contents:
1 distinct polypeptide molecule
2 distinct DNA molecules
Macromolecules (3 distinct):
cAMP-activated global transcriptional regulator CRP Chains: A, B
Molecule details ›
Chains: A, B
Length: 209 amino acids
Theoretical weight: 23.54 KDa
Source organism: Escherichia coli
Expression system: Escherichia coli
UniProt:
  • Canonical: P0ACJ8 (Residues: 2-210; Coverage: 100%)
Gene names: JW5702, b3357, cap, crp, csm
Sequence domains:
Structure domains:
5'-D(*GP*CP*GP*AP*AP*AP*AP*GP*TP*GP*TP*GP*AP*C)-3' Chains: C, E
Molecule details ›
Chains: C, E
Length: 14 nucleotides
Theoretical weight: 4.35 KDa
Source organism: Synthetic construct
Expression system: Not provided
5'-D(*AP*TP*AP*TP*GP*TP*CP*AP*CP*AP*CP*TP*TP*TP*TP*CP*G )-3' Chains: D, F
Molecule details ›
Chains: D, F
Length: 17 nucleotides
Theoretical weight: 5.15 KDa
Source organism: Synthetic construct
Expression system: Not provided

Ligands and Environments

1 bound ligand:

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: CHESS BEAMLINE F1
Spacegroup: C2221
Unit cell:
a: 136.99Å b: 152.8Å c: 76.06Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.199 0.199 0.279
Expression systems:
  • Escherichia coli
  • Not provided
