Trp-Asp. Cluster 3

Cluster 3. Size 41 ( 22.37 st. devs. from mean )

Sequence separations

Separation along the main-chain between the two contacting residues.

          i  ->  i + 2          0
          i  ->  i + 3          0
          i  ->  i + 4          2  **
          i  ->  i + 5          2  **
          i  ->  i + 6         12  ************
          i  ->  i + 7          1  *
          i  ->  i + 8+        53  ********************+

R.m.s. distance ranges

R.m.s. distance ranges of cluster members from representative sidechain.

            Distance
              range       Count
            0.0-0.1           0
            0.1-0.2           0
            0.2-0.3           0
            0.3-0.4           0
            0.4-0.5           1  *
            0.5-0.6           1  *
            0.6-0.7           0
            0.7-0.8           4  ****
            0.8-0.9           4  ****
            0.9-1.0           5  *****
            1.0-1.1           3  ***
            1.1-1.2           7  *******
            1.2-1.3           7  *******
            1.3-1.4           3  ***
            1.4-1.5           5  *****
