PDBe 5vz5

X-ray diffraction
2.59Å resolution

Crystal structure of an anaplastic lymphoma kinase-derived neuroblastoma tumor antigen bound to the Human Major Histocompatibility Complex Class I molecule HLA-B*1501

Released:

Function and Biology Details

Structure analysis Details

Assembly composition:
hetero trimer (preferred)
Entry contents:
3 distinct polypeptide molecules
Macromolecules (3 distinct):
HLA class I histocompatibility antigen, B-15 alpha chain Chain: A
Molecule details ›
Chain: A
Length: 280 amino acids
Theoretical weight: 32.35 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli BL21
UniProt:
  • Canonical: NEW P30464 (Residues: 25-304; Coverage: 83%)
Gene names: HLA-B, HLAB
Sequence domains:
Beta-2-microglobulin Chain: B
Molecule details ›
Chain: B
Length: 100 amino acids
Theoretical weight: 11.88 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli BL21
UniProt:
  • Canonical: NEW P61769 (Residues: 21-119; Coverage: 100%)
Gene names: B2M, CDABP0092, HDCMA22P
Sequence domains: Immunoglobulin C1-set domain
ALK tyrosine kinase receptor Chain: C
Molecule details ›
Chain: C
Length: 10 amino acids
Theoretical weight: 1.25 KDa
Source organism: Homo sapiens
Expression system: Not provided
UniProt:
  • Canonical: NEW Q9UM73 (Residues: 1274-1283; Coverage: 1%)
Gene name: ALK

Ligands and Environments

2 bound ligands:

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: ALS BEAMLINE 5.0.1
Spacegroup: P6122
Unit cell:
a: 112.89Å b: 112.89Å c: 177.38Å
α: 90° β: 90° γ: 120°
R-values:
R R work R free
0.218 0.216 0.265
Expression systems:
  • Escherichia coli BL21
  • Not provided
