PDBe 5ukm

X-ray diffraction
3.03Å resolution

bovine GRK2 in complex with human Gbetagamma subunits and CCG258208 (14as)

Released:

Function and Biology Details

Reaction catalysed:
ATP + [beta-adrenergic receptor] = ADP + [beta-adrenergic receptor] phosphate
Biochemical function:
Cellular component:

Structure analysis Details

Assembly composition:
hetero trimer (preferred)
Entry contents:
3 distinct polypeptide molecules
Macromolecules (3 distinct):
Beta-adrenergic receptor kinase 1 Chain: A
Molecule details ›
Chain: A
Length: 695 amino acids
Theoretical weight: 80.58 KDa
Source organism: Bos taurus
Expression system: Trichoplusia ni
UniProt:
  • Canonical: P21146 (Residues: 1-689; Coverage: 100%)
Gene names: ADRBK1, GRK2
Sequence domains:
Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1 Chain: B
Molecule details ›
Chain: B
Length: 350 amino acids
Theoretical weight: 38.53 KDa
Source organism: Homo sapiens
Expression system: Trichoplusia ni
UniProt:
  • Canonical: P62873 (Residues: 2-340; Coverage: 100%)
Gene name: GNB1
Sequence domains: WD domain, G-beta repeat
Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2 Chain: G
Molecule details ›
Chain: G
Length: 71 amino acids
Theoretical weight: 7.86 KDa
Source organism: Homo sapiens
Expression system: Trichoplusia ni
UniProt:
  • Canonical: P59768 (Residues: 1-71; Coverage: 100%)
Gene name: GNG2
Sequence domains: GGL domain

Ligands and Environments

3 bound ligands:

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: APS BEAMLINE 21-ID-D
Spacegroup: C2
Unit cell:
a: 189.012Å b: 74.15Å c: 123.175Å
α: 90° β: 115.46° γ: 90°
R-values:
R R work R free
0.2 0.197 0.252
Expression system: Trichoplusia ni
