PDBe 5ghv

X-ray diffraction
2.8Å resolution

Crystal structure of an inhibitor-bound Syk

Released:

Function and Biology Details

Reaction catalysed:
ATP + a [protein]-L-tyrosine = ADP + a [protein]-L-tyrosine phosphate
Biochemical function:
  • not assigned
Biological process:
  • not assigned
Cellular component:
  • not assigned

Structure analysis Details

Assembly composition:
monomeric (preferred)
Entry contents:
1 distinct polypeptide molecule
Macromolecule:
Tyrosine-protein kinase SYK Chains: A, B
Molecule details ›
Chains: A, B
Length: 290 amino acids
Theoretical weight: 33.9 KDa
Source organism: Homo sapiens
Expression system: Spodoptera frugiperda
UniProt:
  • Canonical: P43405 (Residues: 356-635; Coverage: 44%)
Gene name: SYK
Sequence domains: Protein tyrosine kinase
Structure domains:

Ligands and Environments

1 bound ligand:

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: PAL/PLS BEAMLINE 7A (6B, 6C1)
Spacegroup: P1
Unit cell:
a: 40.269Å b: 41.501Å c: 85.091Å
α: 89.99° β: 90.01° γ: 98.9°
R-values:
R R work R free
0.217 0.217 0.227
Expression system: Spodoptera frugiperda
