PDBe 5cf5

X-ray diffraction
2.45Å resolution

CRYSTAL STRUCTURE OF JANUS KINASE 2 IN COMPLEX WITH N,N-DICYCLOPROPYL-7-[(DIMETHYL-1,3-THIAZOL-2-YL)AMINO]-10-ETHYL-3-METHYL-3,5,8,10-TETRAAZATRICYCLO[7.3.0.02,6] DODECA-1(9),2(6),4,7,11-PENTAENE-11-CARBOXAMIDE

Released:

Function and Biology Details

Reaction catalysed:
ATP + a [protein]-L-tyrosine = ADP + a [protein]-L-tyrosine phosphate
Biochemical function:
  • not assigned
Biological process:
  • not assigned
Cellular component:
  • not assigned

Structure analysis Details

Assembly composition:
monomeric (preferred)
Entry contents:
1 distinct polypeptide molecule
Macromolecule:
Tyrosine-protein kinase JAK2 Chains: A, B
Molecule details ›
Chains: A, B
Length: 321 amino acids
Theoretical weight: 37.87 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: O60674 (Residues: 839-1132; Coverage: 26%)
Gene name: JAK2
Sequence domains: Protein tyrosine kinase
Structure domains:

Ligands and Environments

1 bound ligand:

1 modified residue:

Experiments and Validation Details

Entry percentile scores
X-ray source: APS BEAMLINE 17-BM
Spacegroup: P41
Unit cell:
a: 111.92Å b: 111.92Å c: 70.26Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.187 0.186 0.199
Expression system: Escherichia coli
