PDBe 5c0i

X-ray diffraction
1.53Å resolution

Function and Biology Details

Structure analysis Details

Assembly composition:
hetero trimer (preferred)
Entry contents:
3 distinct polypeptide molecules
Macromolecules (3 distinct):
Marker peptide Chain: C
Molecule details ›
Chain: C
Length: 10 amino acids
Theoretical weight: 1.18 KDa
Source organism: Homo sapiens
Expression system: Not provided
Beta-2-microglobulin Chain: B
Molecule details ›
Chain: B
Length: 100 amino acids
Theoretical weight: 11.88 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P61769 (Residues: 21-119; Coverage: 100%)
Gene names: B2M, CDABP0092, HDCMA22P
Sequence domains: Immunoglobulin C1-set domain
HLA class I histocompatibility antigen, A-2 alpha chain Chain: A
Molecule details ›
Chain: A
Length: 277 amino acids
Theoretical weight: 32.08 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P01892 (Residues: 25-300; Coverage: 81%)
Gene names: HLA-A, HLAA
Sequence domains:

Ligands and Environments


No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: DIAMOND BEAMLINE I03
Spacegroup: P21
Unit cell:
a: 55.7Å b: 79.74Å c: 58.08Å
α: 90° β: 115.67° γ: 90°
R-values:
R R work R free
0.161 0.159 0.19
Expression systems:
  • Not provided
  • Escherichia coli
