PDBe 3gok

X-ray diffraction
3.2Å resolution

Binding site mapping of protein ligands

Released:
Source organism: Homo sapiens
Entry author: Scheich C

Function and Biology Details

Reaction catalysed:
ATP + a protein = ADP + a phosphoprotein.
Biochemical function:
Biological process:
Cellular component:
  • not assigned

Structure analysis Details

Assemblies composition:
homo 12-mer
monomeric (preferred)
homo trimer
Entry contents:
1 distinct polypeptide molecule
Macromolecule:
MAP kinase-activated protein kinase 2 Chains: A, B, C, D, E, F, G, H, I, J, K, L
Molecule details ›
Chains: A, B, C, D, E, F, G, H, I, J, K, L
Length: 334 amino acids
Theoretical weight: 38.33 KDa
Source organism: Homo sapiens
Expression system: Spodoptera frugiperda
UniProt:
  • Canonical: P49137 (Residues: 41-364; Coverage: 81%)
Gene name: MAPKAPK2
Sequence domains: Protein kinase domain
Structure domains:

Ligands and Environments

1 bound ligand:

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: DIAMOND BEAMLINE I04
Spacegroup: P212121
Unit cell:
a: 140.208Å b: 183.192Å c: 217.656Å
α: 90° β: 90° γ: 90°
R-values:
R R work R free
0.239 0.238 0.258
Expression system: Spodoptera frugiperda
