PDBe 3rl1

X-ray diffraction
2Å resolution

HIV RT derived peptide complexed to HLA-A*0301

Released:

Function and Biology Details

Structure analysis Details

Assembly composition:
hetero trimer (preferred)
Entry contents:
3 distinct polypeptide molecules
Macromolecules (3 distinct):
HLA class I histocompatibility antigen, A-3 alpha chain Chain: A
Molecule details ›
Chain: A
Length: 274 amino acids
Theoretical weight: 31.63 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P04439 (Residues: 25-298; Coverage: 80%)
Gene names: HLA-A, HLAA
Sequence domains:
Structure domains:
Beta-2-microglobulin Chain: B
Molecule details ›
Chain: B
Length: 100 amino acids
Theoretical weight: 11.88 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P61769 (Residues: 21-119; Coverage: 100%)
Gene names: B2M, CDABP0092, HDCMA22P
Sequence domains: Immunoglobulin C1-set domain
Structure domains: Immunoglobulins
Pol protein Chain: C
Molecule details ›
Chain: C
Length: 9 amino acids
Theoretical weight: 1.01 KDa
Source organism: Human immunodeficiency virus 1
Expression system: Not provided
UniProt:
  • Canonical: Q9YV12 (Residues: 313-321; Coverage: 1%)
Gene name: pol

Ligands and Environments

No bound ligands

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: RIGAKU MICROMAX-007
Spacegroup: P21
Unit cell:
a: 48.953Å b: 71.082Å c: 75.517Å
α: 90° β: 106.66° γ: 90°
R-values:
R R work R free
0.187 0.185 0.222
Expression systems:
  • Escherichia coli
  • Not provided
