PDBe 3gsr

X-ray diffraction
1.95Å resolution

Crystal structure of the binary complex between HLA-A2 and HCMV NLV-M5V peptide variant

Released:

Function and Biology Details

Structure analysis Details

Assembly composition:
hetero trimer (preferred)
Entry contents:
3 distinct polypeptide molecules
Macromolecules (3 distinct):
Beta-2-microglobulin Chain: B
Molecule details ›
Chain: B
Length: 100 amino acids
Theoretical weight: 11.88 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P61769 (Residues: 21-119; Coverage: 100%)
Gene names: B2M, CDABP0092, HDCMA22P
Sequence domains: Immunoglobulin C1-set domain
Structure domains: Immunoglobulins
HCMV pp65 fragment 495-503, variant M5V (NLVPVVATV) Chain: P
Molecule details ›
Chain: P
Length: 9 amino acids
Theoretical weight: 911 Da
HLA class I histocompatibility antigen, A-2 alpha chain Chain: A
Molecule details ›
Chain: A
Length: 274 amino acids
Theoretical weight: 31.75 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P01892 (Residues: 25-298; Coverage: 80%)
Gene names: HLA-A, HLAA
Sequence domains:
Structure domains:

Ligands and Environments

No bound ligands

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: ESRF BEAMLINE ID23-2
Spacegroup: P21
Unit cell:
a: 54.019Å b: 81.011Å c: 57.667Å
α: 90° β: 114.56° γ: 90°
R-values:
R R work R free
0.194 0.193 0.226
Expression system: Escherichia coli
