PDBe 1uqs

X-ray diffraction
3.1Å resolution

The Crystal Structure of Human CD1b with a Bound Bacterial Glycolipid

Released:

Function and Biology Details

Structure analysis Details

Assembly composition:
hetero dimer (preferred)
Entry contents:
2 distinct polypeptide molecules
Macromolecules (2 distinct):
T-cell surface glycoprotein CD1b Chain: A
Molecule details ›
Chain: A
Length: 300 amino acids
Theoretical weight: 33.09 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli BL21
UniProt:
  • Canonical: P29016 (Residues: 17-304; Coverage: 91%)
Gene name: CD1B
Sequence domains: Immunoglobulin C1-set domain
Structure domains:
Beta-2-microglobulin Chain: B
Molecule details ›
Chain: B
Length: 100 amino acids
Theoretical weight: 11.88 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli BL21
UniProt:
  • Canonical: P61769 (Residues: 21-119; Coverage: 100%)
Gene names: B2M, CDABP0092, HDCMA22P
Sequence domains: Immunoglobulin C1-set domain
Structure domains: Immunoglobulins

Ligands and Environments

1 bound ligand:

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: ESRF BEAMLINE ID14-4
Spacegroup: P3121
Unit cell:
a: 96.974Å b: 96.974Å c: 114.834Å
α: 90° β: 90° γ: 120°
R-values:
R R work R free
0.236 0.236 0.29
Expression system: Escherichia coli BL21
