PDBe 1fze

X-ray diffraction
3Å resolution

CRYSTAL STRUCTURE OF FRAGMENT DOUBLE-D FROM HUMAN FIBRIN

Released:

Function and Biology Details

Structure analysis Details

Assemblies composition:
hetero hexamer
hetero trimer (preferred)
Entry contents:
3 distinct polypeptide molecules
Macromolecules (3 distinct):
Fibrinogen alpha chain Chains: A, D
Molecule details ›
Chains: A, D
Length: 87 amino acids
Theoretical weight: 10.24 KDa
Source organism: Homo sapiens
UniProt:
  • Canonical: P02671 (Residues: 130-216; Coverage: 10%)
Gene name: FGA
Structure domains: Single alpha-helices involved in coiled-coils or other helix-helix interfaces
Fibrinogen beta chain Chains: B, E
Molecule details ›
Chains: B, E
Length: 328 amino acids
Theoretical weight: 37.69 KDa
Source organism: Homo sapiens
UniProt:
  • Canonical: P02675 (Residues: 164-491; Coverage: 71%)
Gene name: FGB
Sequence domains: Fibrinogen beta and gamma chains, C-terminal globular domain
Structure domains:
Fibrinogen gamma chain Chains: C, F
Molecule details ›
Chains: C, F
Length: 319 amino acids
Theoretical weight: 36.22 KDa
Source organism: Homo sapiens
UniProt:
  • Canonical: P02679 (Residues: 114-432; Coverage: 75%)
Gene names: FGG, PRO2061
Sequence domains: Fibrinogen beta and gamma chains, C-terminal globular domain
Structure domains:

Ligands and Environments

2 bound ligands:

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: NSLS BEAMLINE X12C
Spacegroup: P21
Unit cell:
a: 108Å b: 48.6Å c: 166.4Å
α: 90° β: 104.4° γ: 90°
R-values:
R R work R free
0.251 0.251 0.318
