PDBe 1fv1

X-ray diffraction
1.9Å resolution

STRUCTURAL BASIS FOR THE BINDING OF AN IMMUNODOMINANT PEPTIDE FROM MYELIN BASIC PROTEIN IN DIFFERENT REGISTERS BY TWO HLA-DR2 ALLELES

Released:

Function and Biology Details

Structure analysis Details

Assembly composition:
hetero trimer (preferred)
Entry contents:
3 distinct polypeptide molecules
Macromolecules (3 distinct):
Myelin basic protein Chains: C, F
Molecule details ›
Chains: C, F
Length: 20 amino acids
Theoretical weight: 2.28 KDa
Source organism: Homo sapiens
Expression system: Not provided
UniProt:
  • Canonical: P02686 (Residues: 218-237; Coverage: 7%)
Gene name: MBP
HLA class II histocompatibility antigen, DR beta 5 chain Chains: B, E
Molecule details ›
Chains: B, E
Length: 190 amino acids
Theoretical weight: 22.23 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: Q30154 (Residues: 30-219; Coverage: 80%)
Gene name: HLA-DRB5
Sequence domains:
Structure domains:
HLA class II histocompatibility antigen, DR alpha chain Chains: A, D
Molecule details ›
Chains: A, D
Length: 181 amino acids
Theoretical weight: 21.08 KDa
Source organism: Homo sapiens
Expression system: Escherichia coli
UniProt:
  • Canonical: P01903 (Residues: 26-206; Coverage: 79%)
Gene names: HLA-DRA, HLA-DRA1
Sequence domains:
Structure domains:

Ligands and Environments

2 bound ligands:

No modified residues

Experiments and Validation Details

Entry percentile scores
X-ray source: NSLS BEAMLINE X12B
Spacegroup: P21
Unit cell:
a: 63.189Å b: 114.892Å c: 63.175Å
α: 90° β: 90.9° γ: 90°
R-values:
R R work R free
0.233 0.233 0.267
Expression systems:
  • Not provided
  • Escherichia coli
